The NEW Secutor LRF’s were built to expand and diversify the line of rangefinder equipped thermal riflescopes in the AGM assortment. Though the Secutor LRF series will utilize the same upgraded thermal sensors that can be found across the majority of AGM’s new products, the three primary differences include an upgraded 1000m laser rangefinder, a digital compass and utilization of a CR123A based power system. These differences, while primarily aimed at more noncommercial tactical applications, still offer both extended ranging and battery familiarity to commercial predator hunters as well. The extended range of the LRF, when paired with the non-proprietary CR123A power system, helps make the Secutor LRF’s a great option for different law enforcement and defense applications. Meanwhile, the integrated compass gives shooters an added layer of situational and positional awareness. The newly introduced sub-20 milikelvin thermal sensors will aid users in these tactical scenarios by increasing their ranging capabilities, as well as increase their ability to both detect and identify targets at longer distances. With both 50 and 75mm options, the Secutor LRF’s provide more authenticity than ever to the phrase: long range.
Detector Type | 12μm VOx Uncooled Focal Plane Array |
Resolution | 640 × 512 |
Refresh Rate | 50 Hz |
Response Waveband | 8 μm to 14 μm |
NETD | Less than 20 mK (@25°C), F#=1.0 |
Lens System | 75 mm; F1.2 |
Field of View (H×V) | 5.9° × 4.7° |
Magnification | 4× – 32× |
Digital Zoom | 1×, 2×, 4×, 8× |
Detection Range (6’ object) | 3,200 m/yd |
Eye Relief | 45 mm |
Exit Pupil | 6 mm |
Diopter Adjustment | -5 to +5 dpt |
Monitor | 1024x768, 0.39 inch, OLED |
FFC (Flat Field Correction) | Auto, Manual, External Correction |
Palettes | Black Hot, White Hot, Red Hot, Fusion |
Reticle | 10 types, 4 colors, on/off |
Boresight Adjustment | Digital Controlled |
Laser Range Finder | Up to 1000 m, ±4 m accuracy |
Laser Wavelength | 905 nm |
Laser Safety Class | Class 1 |
Highest Temperature Spot Tracking | Yes |
Defective Pixel Correction | Yes |
WiFi Hotspot | Yes |
Standby Mode | Yes |
Picture In Picture Mode | Yes |
Burn Prevention | Yes |
Built-in Storage | 16 GB EMMC |
Video/Audio Recording | Yes |
Image Capture | Yes |
Shot Activated Recording (SAR) | Yes |
Battery Type | Four CR123A Lithium batteries |
Battery Operating Time (WiFi off) | Мore than 6 hours |
External Power | 5 VDC/2 A, USB Type-C |
Working Temperature | -30°C to 55°C (-22°F to 131°F) |
Protection Level | IP67 |
Max/ Recoil | 1,000 g / 0.4 ms |
Dimensions (w/o mount) | 250 × 110 × 78 mm (9.8 × 4.3 × 3.1 in) |
Weight (w/o mount and battery) | 0.73 kg (1.61 lb) |
AGM Thermal Targets 25pcs
PART NO.: 633125S1
Long, low profile one-piece mount
PART NO.: 0581RXH
Special, longer weaver mount, low profile, made specifically to fit on Merkel RX Helix and similar rifles.
Length of the mount is 125 mm and spacing between locking levers (center to center) is 110 mm.
Can be used also on Sako S20, CZ600 Alpha and Ergo, Haenel Jaeger NXT, Sabatti Saphire.
Material: Base -> High-grade steel, CNC machined from solid
material, black oxide. Upper part (adapter for NV/Thermal
device) -> high grade aluminium alloy
Recoil lug: milled from solid material (no insert)
Fixation: QR levers - adjustable and can be put in position as
you like
Distance: from first locking point to second 53 mm
Fits: Picatinny rails with minimum length of 90 mm
AGM-2125 ADM quick release mount (for Secutor LRF Series)
PART NO.: 6306X1251
AGM Thermal Targets 50pcs
PART NO.: 633150S1
