The AGM Sidewinder Thermal Monocular series is the newest addition to what is already the most extensive thermal product assortment in the world! The Sidewinder series boasts a wide range of Germanium lens sizes and industry-leading 12 micron, sub- 20mk thermal detectors. These physical attributes provide users with some of the best image quality AGM has produced to date with potential detection ranges up to 2600 meters. The Sidewinders also bring many new advancements to the product category which users have been clamoring for. These handheld monoculars come equipped with the most sensitive thermal sensor on the market, providing users with a stunning advancement in image clarity and background detail. Also, this units utilize a removable, nonproprietary 18650 rechargeable battery which powers the unit by offering up to 7 hours of operating time, built-in to a new robust rubber armored housing for added durability and protection. The Sidewinder also comes packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: F1.0 aperture optics, 50Hz refresh rate, 64GB of built-in memory (highest in its class), Wi-Fi compatibility to pair with the AGM Connect App, an IP67 waterproof rating, USB Type-C port for external power capabilities, 4 color palettes. The Sidewinders are built for well-rounded use and would work great for hunting, farming/herd protection, building security, law enforcement, search & rescue, boating, camping and other general outdoors activities.
Detector Type | 12μm Vanadium Oxide Uncooled Focal Plane Array |
Resolution | 640x512 |
Refresh Rate | 50 Hz |
Response Waveband | 8μm to 14μm |
NETD | ≤ 20 mk (@25°C), F#=1.0 |
Detection Range (6’ object) | 2600 m |
Lens System | 50 mm; F0.9 |
Field of View (H × V) | 8.7° × 7° |
Magnification | 2.5× - 20× |
Digital Zoom | 1×, 2×, 4×, 8× |
Diopter Adjustment | -5 to +3 dpt |
Monitor | 1024×768, OLED |
FFC (Flat Field Correction) | Auto, Manual, External Correction |
Palettes | Black Hot, White Hot, Red Hot, Fusion |
Image Boost | Yes |
Highest Temperature Spot Tracking | Yes |
Wi-Fi Hotspot | Yes |
Standby Mode | Yes |
Storage | Built-in memory (64 GB) |
Video Recording/Audio | Yes / Yes (on-board) |
Image Capture | Yes |
Battery Type | One 18650 Replaceable rechargeable Lithium battery |
Battery Operating Time | Up to 5 hours |
Power | 5 VDC/2 A, 2.1 W |
Interface | USB Type-C |
Working Temperature | -30°C to 55°C (-22°F to 131°F) |
Protection Level | IP67 |
Dimensions | 200 × 78 × 68 mm (7.9 × 3.0 × 2.7 in) |
Weight | 636 g (1.4 lb) |
